Steel structure design drawings are divided into two stages: design drawings and construction drawings. Design drawings shall be provided by the designer. Construction drawings are usually prepared by steel structure manufacturing enterprises according to design drawings, sometimes by design units. In recent years, due to the contradiction between the increase of steel structure projects and the lack of steel structure engineers, it is common for Jinan light steel structure company with design ability to participate in the preparation of design drawings.

　　1.設計圖紙:為廠家制作詳圖提供依據。深度和內容應該是完整的，但不是多余的。設計圖紙應包括設計依據、荷載數據(包括抗震作用)、技術數據、材料選擇和材料要求、設計要求(包括制造安裝、焊縫質量檢驗等級、涂裝、運輸)。結構的布置、構件截面的選擇、結構的主要節點的施工應明確，以便順利編制詳細的施工圖，正確反映設計意圖。主要材料應列入清單。

　　1. Design drawings: provide basis for manufacturer to make detailed drawings. Depth and content should be complete, but not redundant. Design drawings shall include design basis, load data (including seismic action), technical data, material selection and material requirements, design requirements (including manufacturing and installation, weld quality inspection level, coating and transportation). The layout of the structure, the selection of component sections and the construction of main nodes of the structure shall be clear, so as to smoothly prepare detailed construction drawings and correctly reflect the design intent. Main materials shall be listed.

　　2.施工詳圖:又稱加工圖或放樣圖。深度應足以在車間直接制造和加工。其他不完全相同的部分應當單獨陳述，并附詳細的材料清單。

　　2. Construction details: also known as processing drawing or setting out drawing. The depth shall be sufficient for direct shop fabrication and processing. Other parts that are not identical shall be stated separately with detailed material list attached.

　　目前，對設計圖紙和施工圖的內容表達方法以及施工圖深度的控制進行了研究。不同的設計公司與鋼結構公司之間存在差異。初學者可以參考別人的優秀設計，參考相關參考書[3]，根據說明書進行準備。

　　At present, the content expression method and depth control of design drawings and construction drawings are studied. There are differences between different design companies and steel structure companies. Beginners can refer to other people's excellent design, refer to the relevant reference book [3], and prepare according to the instructions.
